LKV223P

4K@30Hz point to point HDMI™ Extender PoC 70M

This HDMI™ Extender includes a transmitter unit and a receiver unit, allows the HDMI™ signal to be transmitted up to 70 meters using a Cat6/6A/7 network cable. It adopts a point-to-point connection configuration, supports bi-directional IR pass-back and 3.5 mm stereo audio output. It is perfect for outdoor advertising, monitor system, home entertainment, conference, etc.

Introduction

Parameters

Downloads


Voltage/Current

DC5 V / 2A

Power consumption

TX<4W RX<4W

HDMI compliance

HDMI 1.4

HDCP compliance

HDMI 1.4

HDMI resolution

800x600, 1024x768, 1280x720, 1280x960, 1366x768, 1440x900, 1680x1050, 1920x1080, 480i@60Hz, 480p@60Hz, 576i@50Hz, 576p@50Hz, 720p@50/60Hz, 1080i@50/60Hz, 1080p@24/25/30/50/60Hz, 3840x2160@24/25/30Hz

Supports audio formats

PCM, LPCM, DTS HD, DTS Audio

Input and output TMDS signal

0.7~1.2Vp-p(TMDS)

Input and output DDC signal

5Vp-p(TTL)

Input cable length

≤8m(AWG24)

Output cable length

≤8m(AWG24)

Cat6/6A/7 Transmission Distance

1080p@60Hz transmission 70 meters
4K@30Hz transmission 40 meters

Electrostatic protection of the whole machine

Implementation of the standard:
IEC61000-4-2
1a Contact discharge Level 2 (±4KV)
1b Air discharge Level 3 (±8KV)

Working temperature

-20~60℃

Storage temperature

-30~70℃

Humidity (no condensation)

0～90%RH

Dimension

75.0(L) x 80.0(W) x 18.0(H)mm

Material

Aluminum alloy material + crystal panel

Treatment process

Grit blas

Color

Black

Weight

TX：160g，RX：160g
