HDMI Length
≤5m
Maximum transfer rate
18Gbps
Maximum transmission bandwidth
600MHz
EDID passthrough
Yes
Compatibility
HDMI 2.0（Deep color, 4K, HDR, YUV4:4:4）
HDCP 2.2
Resolutions
720p@50/60Hz、1080i@50/60Hz、1080p@50/60Hz、 3840x2160@24/25/30/50/60Hz、4096x2160@24/25Hz、 1280x960、1280x800、1280x768、1680x1050、 1360x768、1366x768、1600x900、1024x768、800x600
Transmission distance
CAT6/6A/7≤70m
Audio formats
LPCM/DTS-HD/DTS-Audio/Dolby Digital 5.1CH/Dolby Atmos
IR interface
TX：1x 3.5mm IR OUT Female
RX：1x 3.5mm IR IN Female
Receiving range ≤
≤5m
Infrared frequency
20KHz~60KHz
Power Supply
TX：DC5V/2A
RX：DC5V/2A
Power Consumption
TX：＜4W
RX：＜4W
Working temperature
-20℃~60℃
Storage temperature
-30℃~70℃
Humidity
0~90%RH（No condensation）
Housing
Metal
Weight
TX：140g
RX：140g
Color
Black
Dimensions
TX/RX：85.0(L)*75.5(W)*16.5(H)mm
Protection
ESD protection
1a Contact discharge level 2 (±4KV)
1b Air discharge level 3 (±8KV)
Implementation of the standard: IEC61000-4-2
Lightning protection, Surge protection
